| Technical Specifications | |
|---|---|
| DC output connection: |
|
| Charging mode | CCS1 or CHAdeMO |
| Output power | 7/12kW |
| Output voltage | CCS1: 150V DC-950V DC, CHAdeMO: 150V DC-500V DC |
| Output current | 40A @ 300V |
| Number of outputs | 1*CCS1 or 1*CHAdeMO |
| Peak efficiency | ≥97% |
| AC input connection |
|
| Earthing system | L1/L2/PE |
| Input voltage | 208/240Vac
|
| Input frequency | 60Hz |
| Power factor | ≥0.99 |
| Harmonic distortion (THDi) | ≤5% |
| General characteristics |
– |
| IP and IK rating | NEMA 4X |
| Operating altitude | 2000m |
| Operating temperature range | -25℃~+50℃ |
| Storage temperature range | -40℃~+85℃ |
| Mounting | Wall or floor using a pedestal |
| Dimensions (H×W×D) | 711×386×170mm |
| User interface |
|
| Status indication | LED/APP |
| Cable Length | 5m |
| User interface | Autel Charge APP; Autel Charge Cloud |
| Connectivity | Bluetooth, Wi-Fi, Ethernet, CAN, RS485 |
| Communication protocols | OCPP 1.6J (Can be upgraded to OCPP 2.0.1 later) |
| User authentication | APP, RFID card |
| Software update |
|
| Software update | OTA updates via web portal |
| Certification and standards | |
| Safety and Compliance | UL2202, CSA C22.2 No.107.1, UL9741, UL 1741:2021, CSA 22.2.107.1:2016, NEC Article 615 |
| Grid standards | UL 1741 SA/SB:2021, IEEE 1547:2018, IEEE 1547.1:2020, Rule 21, HECO Rule 14; IEEE 1547.1:2022; Interoperability testing; PRD-024-1 |
| EMC compliance | FCC 15 Class B |
| Certification | Energy Star, OpenADR 2.0b |
| Warranty | 24 months, warranty extension possible |
Size Guides
SIZE GUIDE
Sofas
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| Height | 88 | 89 | 90 | 91 | 92 | 93 |
| Width | 55 | 56 | 58 | 59 | 62 | 65 |
| Length | 90 | 92 | 94 | 95 | 96 | 98 |
Chair
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| Height | 60 | 62 | 65 | 66 | 68 | 69 |
| Width | 50 | 55 | 58 | 62 | 65 | 66 |
| Length | 80 | 82 | 85 | 86 | 88 | 89 |
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
Bi-Directional Power Conversion
Designed to be More than just a Fast Charger
- 12kW bi-directional power supports fast charging and provides supplemental power when needed
- ENERGY STAR® certified means you use less energy and ultimately save money
Intelligent Switching Tech
Reliable Backup Power Under Multiple Situations
- During a blackout Auto Switch-on automatically disengages your home from the grid, and uses your EV to power your home
- The app or the cloud can be configured to divert energy from your vehicle to power your home during peak times when energy costs are the highest, saving your money
- V2X comes with future ready technology compatible with Home Energy Management System (HEMS)
Smart Micro-Grid
Built for Energy Savings and a Green Future
- When integrated with solar and energy storage your EV becomes a micro-grid, and our V2X charger enables intelligent power management distribution to cover energy demand changes and charges
- By redistributing energy back to the grid, you may be able to participate in green energy trading, helping to save electricity and reduce your electric bill
